Part Number Vrwm(V)Ir(μA)Vbr min.(V)8/20μs Current Ipp(A)Cj(pF)Package 搜索

BV-FA05UA 5V ≤1μA 5.4V 4A 0.8pF DFN1006
BV-FA05UCA 5V 0.1μA 6V 4A 0.4pF DFN1006
BV-FA05UCB 5V 0.05μA 6V 4A 0.5pF DFN1006
BV-FA05ZCD 5V 0.5μA 5.6V 5A 18pF DFN1006
BV-D505ZC 5V ≤1μA 5.6V 8A ≤15pF SOD523FL
BV-D505ZCB 5V 2μA 5.2V 3A ≤7pF SOD523FL
BV-FE4.5ZCA 4.5V ≤1μA 4.8V 160A ≤1500pF DFN1610
BV-FE05ZA 5V ≤1μA 6V 140A ≤2000pF DFN1610
BV03C 3V 20μA 4V 8A 1.5pF SOD-323
BV03C-H 3.3V 1μA 4V 19A 1.5pF SOD-323
BV05C 5V 5μA 6V 8A 1.5pF SOD-323
BV05C-H 5V 5μA 6V 17A 1.5pF SOD-323
BV08C 8V 2μA 8.5V 8A 1.5pF SOD-323
BV12C 12V 1μA 13.3V 8A 1.5pF SOD-323
BV15C 15V 1μA 16.7V 5A 1.5pF SOD-323
BV15C-H 15V 1μA 16.7V 10A 1.5pF SOD-323
BV24C 24V 1μA 26.7V 3A 1.5pF SOD-323
BV-D303UCB 3V ≤0.5μA 3.5V 10A ≤1pF SOD-323
BV-D303ZCB 3.3V ≤40μA 4V 20A ≤450pF SOD-323
BV-D305ZH 5V ≤1μA 6V 130A ≤2000pF SOD-323
BV-D305ZB 5V ≤1μA 6V 17A ≤400pF SOD-323
BV-D324ZCB 24V ≤1μA 26.7V 5.5A ≤50pF SOD-323
BV-D336ZCB 36V ≤1μA 40V 3A ≤35pF SOD-323
BV-D105ZCF 5V ≤800μA 6.4V 1000W / SOD-123F
BV-D106ZCF 6V ≤800μA 6.67V 1000W / SOD-123F
BV-D16.5ZCF 6.5V ≤300μA 7.22V 1000W / SOD-123F
BV-D112ZB 12V ≤1μA 13.3V 170A ≤1500pF SOD-123F
BV-D124ZCF 24V ≤1μA 26.7V 1000W / SOD-123F
BV-D136ZCF 36V ≤1μA 40V 1000W / SOD-123F
