首页>>TVS | 瞬态抑制二极管>>PTVS大通流型PTVS大通流型
| Part Number | Vrwm(V)截止电压 | Ir(μA)漏电流 | Vbr(V)击穿电压 | It(mA)测试电流 | Vc(V)钳位电压 | Ipp(A)峰值电流 | 搜索 | |
| BV-SMEJ66CA | 66 | 10 | 72~80 | 10 | 120 | 10000 | ||
| BV-SMEJ76CA-H | 76 | 10 | 85~95 | 10 | 140 | 10000 | ||
| BV-SMEJ86CA-H | 86 | 10 | 95~105 | 10 | 157 | 10000 | ||
| AK6-030C | 30 | 10 | 32~37 | 10 | 90 | 6000 | ||
| AK6-042C | 42 | 10 | 47~51 | 10 | 105 | 6000 | ||
| AK6-058C | 58 | 10 | 64~70 | 10 | 110 | 6000 | ||
| AK6-066C | 66 | 10 | 72~80 | 10 | 120 | 6000 | ||
| AK6-076C | 76 | 10 | 85~95 | 10 | 140 | 6000 | ||
| AK10-030C | 30 | 10 | 32~37 | 10 | 90 | 10000 | ||
| AK10-058C | 58 | 10 | 64~70 | 10 | 110 | 10000 | ||
| AK10-066C | 66 | 10 | 72~80 | 10 | 120 | 10000 | ||
| AK10-076C | 76 | 10 | 85~95 | 10 | 140 | 10000 | ||
| AK10-380C | 380 | 10 | 401~443 | 10 | 520 | 10000 | ||
| HFA-030L | 30 | 20 | 33 | 1 | 100 | 3000 | ||
| HFA-042L | 42 | 20 | 47 | 1 | 105 | 3000 | ||
| HFA-076L | 76 | 20 | 85 | 1 | 140 | 3000 | ||
| HFA-170L | 170 | 20 | 180 | 1 | 260 | 3000 | ||
| HFA-190L | 190 | 20 | 200 | 1 | 290 | 3000 | ||
| HFB-030L | 30 | 20 | 33 | 1 | 100 | 6000 | ||
| HFB-042L | 42 | 20 | 47 | 1 | 105 | 6000 | ||
| HFB-058L | 58 | 20 | 64 | 1 | 110 | 6000 | ||
| HFB-066L | 66 | 20 | 70 | 1 | 120 | 6000 | ||
| HFB-076L | 76 | 20 | 85 | 1 | 140 | 6000 | ||
| HFC-030L | 30 | 20 | 33 | 1 | 100 | 10000 | ||
| HFC-076L | 76 | 20 | 85 | 1 | 140 | 10000 | ||
| HFC-380L | 380 | 20 | 401 | 1 | 520 | 10000 | ||
| HFC-430L | 430 | 20 | 440 | 1 | 650 | 10000 |
