Part Number DC Spark-over Voltage 100V/s(V)Impulse Voltage1000V/us(V)Impulse Current 8/20μs(KA)Capacitance 0.5V 1MHZ(pF)Size L*W*H(mm) 搜索

B5G070L 70V ≤650V 5KA ≤1pF Φ5.5*6
B5G090L 90V ≤650V 5KA ≤1pF Φ5.5*6
B5G230L 230V ≤700V 5KA ≤1pF Φ5.5*6
B5G470L 470V ≤850V 5KA ≤1pF Φ5.5*6
B5G600L 600V ≤950V 5KA ≤1pF Φ5.5*6
B5G800L 800V ≤1600V 5KA ≤1pF Φ5.5*6
B5G1000L 1000V ≤1600V 5KA ≤1pF Φ5.5*6
B5G3600 3600V ≤4700V 3KA ≤1pF Φ5.5*6
B8G090L 90V ≤650V 5KA ≤1.5pF Φ8*6
B8G090M 90V ≤650V 10KA ≤1.5pF Φ8*6
B8G090H 90V ≤650V 20KA ≤1.5pF Φ8*6
B8G600L 600V ≤1400V 5KA ≤1.5pF Φ8*6
B8G600M 600V ≤1400V 10KA ≤1.5pF Φ8*6
B8G600H 600V ≤1400V 20KA ≤1.5pF Φ8*6
B8G800L 800V ≤1600V 5KA ≤1.5pF Φ8*6
B8G800M 800V ≤1600V 10KA ≤1.5pF Φ8*6
B8G1000M 1000V ≤1600V 10KA ≤1.5pF Φ8*6
B8G2000L 2000V ≤2750V 5KA ≤1.5pF Φ8*6
B8G2500L 2500V ≤4200V 5KA ≤1.5pF Φ8*6
B8G3600L 3600V ≤6000V 5KA ≤1.5pF Φ8*6
